Components for electrical installation
The quality and service life of switchgear depends decisively on the selection of the technology used. Woertz offers a wide range of high-quality components for every application in electrical installation technology
Product systems
- Earthing material
- EMC
- Fastening technology
- Accessories electrical components
- Relays and power supplies
- Housings and cans
- Passive EMC - Shield Terminals
1
- IP65 International Protection
- Color RAL 7035, light gray
- Quick-release fastener made of stainless steel, self-retaining
- With neoprene seal (available on request, with silicone seal)
1
- 6x1.5 mm²
- IP65 International Protection
- housing unpainted
- with internal protection clamp
- jet water proof
- for thread up to max. 4xM20 price level for metric thread: size 0
1
- IP65 International Protection
- Cast iron housing, hot-dip galvanized
- With internal protective conductor terminal no. 2860, 4 mm²
- Hinged cover with square screw plug 8 mm
- for thread in the protective cover ...
1
- IP65 International Protection
- Cast iron housing
- With internal protective conductor terminal no. 2860 4 mm²
- Splash-proof
- for threads up to max. 8xM20 or 4xM25
- for the installation of steatite clamping rings...
1
- 7x2.5 mm²
- IP54 International Protection DIN 40050
- With two swivel mounting lugs
- For steatite clamping rings series 2505 ..., with one-screw terminals, with anti-spread ring, made of nickel-plated brass
1
- for dry installations only
- two-piece housing with pre-marked knockouts
- With one screw terminals, with anti-spread ring, for continuous conductors, made of nickel-plated brass. In steatite base
1
- IP65 International Protection
- Color RAL 7000, fehgrau
- Cover screws made of stainless steel, captive
- With neoprene seal (available on request, with silicone seal)
1
- With bolt and with spring
- Profile rail No. 4384 serves as busbar
- Remove cable sheath, expose shield
- Handle like quick installer
- With steel spring that creates contact without damaging shield
- Do not use as ...
1
- 5x2.5 mm²
- IP54 International Protection DIN 40050
- heavily combustible
- impact resistant
- splashproof
- with center bolt
- with central cover mounting screw
- with two external mounting tabs
2
- With pin and with spring
- Profile rails No. 4382,4383 and 80291, type C30 serves as busbar
- Remove cable sheath, expose shield
- Handle like quick installer
- With steel spring that creates contact without dama...
3
- With bolt and with spring
- The profile rails serve as busbar
- Remove cable sheath, expose shield
- Handle like quick installer
- With steel spring that creates contact without damaging shield
- Do not use as a cab...
4
- With screw and with stainless steel spring
- The profile rails serve as a busbar
- Is suitable for installations where strong vibrations and large temperature differences may occur
- With spring to prevent ind...
5
- IP65 International Protection
- Enclosure unpainted
- With internal protective conductor terminal 2.5 - 16 mm² No. 2863
- jet-proof
- for threads up to max. 12xM32, 8xM40 or 8xM50
- with built-in mounting rail DIN32...
5
- 6x2.5 mm²
- IP65 International Protection
- Unpainted housing
- With internal protective conductor terminal no. 2860, 4 mm²
- jet-proof
- for threads up to max. 8xM20 or 4xM25 Price level for metric threads: Gr. 0
5
- IP65 International Protection
- Grey cast iron housing phosphated and painted gray
- With internal protective conductor terminal no. 2860, 4 mm²
- jet-proof
- for threads up to max. 6xM32 or 4xM40
- for the installa...
5
- IP65 International Protection
- Color RAL 7035, light gray
- Quick-release fastener made of stainless steel, self-retaining
- With neoprene seal (available on request, with silicone seal)
- UV resistant
5
- Remove cable sheath, expose shielding
- Handle like quick-fit
- Nickel-plated brass
- with spring made of steel, which creates the contact without damaging the
- Never use as a cable fastener!
5
- 5x10 mm²
- IP54 International Protection DIN 40050
- with two swiveling mounting lugs
- for two-screw branch terminals series 30840..., 5x10 mm²
10
- IP65 International Protection
- Enclosure unpainted
- With internal protective conductor terminal 2.5 - 16 mm² No. 2863
- jet-proof
- for threads up to max. 8xM20 or 4xM25 Price level for metric threads: Gr. II
10
- IP65 International Protection
- Grey cast iron housing phosphated and painted gray
- With internal protective conductor terminal no. 2860, 4 mm²
- splash-proof
- for threads up to max. 6xM32 or 2xM40
- for the insta...
10
- 5x35 mm²
- IP54 International Protection DIN 40050
- With two swivel mounting lugs
- for two screw-type branch terminals series 30840 ..., 5x10 mm²
15
- IP65 International Protection
- Enclosure unpainted
- With internal protective conductor terminal 2.5 - 16 mm² No. 2863
- jet-proof
- for threads up to max. 12xM32 or 8xM40 or 8xM50 Price level for metric threads...
15
- IP65 International Protection
- Grey cast iron housing phosphated and painted gray
- With internal protective conductor terminal no. 2860, 4 mm²
- splash-proof
- for threads up to max. 6xM32 or 4xM40
20
- IP65 International Protection
- Grey cast iron housing phosphated and painted gray
- With internal protective conductor terminal no. 2861, 6 mm²
- splash-proof
- for threads up to max. 6xM40 or 4xM50
25
- IP65 International Protection
- Grey cast iron housing phosphated and painted gray
- With internal protective conductor terminal no. 2864, 35 mm²
- jet-proof
- for threads up to max. 8xM50
- for the installation of ...
100
- made of glass fiber reinforced PA 66 25 %
- for screwing on
- for insertion in profile rails no. 4382 and 4383.
110
- IP65 International Protection
- Enclosure unpainted
- With internal protective conductor terminal 2.5 - 16 mm² No. 2863
- jet-proof
- for threads up to max. 8xM40 or 4xM50
- with built-in mounting rail DIN32 mm acco...
10007
Everything you need to know about lightning protection systems, their core components and the Electrosuisse 4022 guidelines. Read here how the earth electrodes described so far can also be used for li...
10010
Various plug-in contacts for equipotential bonding.
Find out what special measures need to be taken when using a conductor laid in a concrete foundation, also known as a banderder.
A comprehensive look at the radial earth electrode, which serves as a supplement for systems with insufficient earth contact resistance. The precise laying of the earth electrode directly in the groun...
An in-depth look at the earth electrode, which is used to supplement systems with insufficient earth contact resistance. Learn new details about direct installation in the ground and which conditions ...
Various cable clamps for screwing on and inserting into profile rails.
Various end caps, corner pieces, angle pieces and cross connectors.
This overview focuses on the importance of connection points as a central element for a permanent earthing connection. It explains why they must be watertight and corrosion-resistant and must be able ...
Various connection sets with copper conductors for connecting foundation grounding electrodes to the connection points.
A detailed look at protective equipotential bonding (SPA), also known as main equipotential bonding. Learn how this electrically conductive connection creates the same potential between bodies of equi...
